Refrigerated Compressed Air Dryer
description
| Rated Working Conditions | |||||||
| 01 | Intake Temperature: ≤40℃ or Install a precooler | ||||||
| 02 | Working Pressure: 0.4 ~ 1.6 MPa or customizable | ||||||
| 03 | Temperature Drop: 8 ~ 10℃ | ||||||
| 04 | Pressure Drop: ≤3% | ||||||
| 05 | Ambient Temperature: ≤38℃ (Air-cooled Type) | ||||||
| 06 | Cooling Water Temperature: ≤32℃ (Water-cooled Type) | ||||||
| 07 | Cooling Water Pressure: 0.2 ~ 0.5 MPa | ||||||
| 08 | Outlet Dew Point (PDP): 2 ~ 10℃ | ||||||
| 09 | Refrigerant: R22/R134a/R407c/R410a or customizable | ||||||
| 10 | Power Supply: 220V/1Ph/50Hz or 380V/3Ph/50Hz or customizable | ||||||
| Product Selection Table | |||||
| If you have special requirements, you can contact us to customize products | |||||
| Model | Capacity Nm³/min | Power kW | Interface Diameter | Dimension (LxWxH) mm | Weight kg |
| LNLF-1 | 1 | 0.27 | Rp 1" | 600x450x815 | 79 |
| LNLF-1.6 | 1.6 | 0.37 | Rp 1" | 600x450x815 | 87 |
| LNLF-2.6 | 2.6 | 0.46 | Rp 1" | 650x500x875 | 94 |
| LNLF-3.8 | 3.8 | 0.67 | Rp 1" | 650x500x975 | 110 |
| LNLF-6.5 | 6.5 | 1.26 | Rp 1 ½" | 650x650x090 | 176 |
| LNLF-8.5 | 8.5 | 1.53 | Rp 1 ½" | 650x650x090 | 220 |
| LNLF-11.5 | 11.5 | 1.92 | Rp 2" | 850x700x1230 | 275 |
| LNLF-13.5 | 13.5 | 2.29 | Rp 2" | 900x750x1230 | 308 |
| LNLF-17 | 17 | 2.59 | DN65 | 900x750x1240 | 482 |
| LNLF-20 | 20 | 3.24 | DN65 | 1000x850x1330 | 539 |
| LNLF-25 | 25 | 4.56 | DN80 | 1000x850x1330 | 561 |
| LNLF-35 | 35 | 5.21 | DN100 | 1210x1000x1460 | 825 |
| LNLF-40 | 40 | 6.26 | DN100 | 1310x1100x1460 | 935 |
| LNLF-50 | 50 | 6.83 | DN100 | 1360x1150x1460 | 979 |
| Note: LNLF is Air-Cooled type, others can be customized. Welcome to inquire for more details, WhatsApp No. +86 139 5809 5893 or E-mail: luther.liu@hzlinuo.com | |||||
| Product Selection Table | |||||||
| If you have special requirements, you can contact us to customize products | |||||||
| Model | Capacity Nm³/min | Power kW | Interface Diameter | Dimension (LxWxH) mm | Weight kg | Water Volume m³/hour | Water Pipe Diameter |
| LNLS-20 | 20 | 2.82 | DN65 | 1100X800X1000 | 550 | 1.9 | Rp 1" |
| LNLS-25 | 25 | 4.14 | DN80 | 1100X800X1000 | 585 | 2.6 | Rp 1" |
| LNLS-35 | 35 | 4.54 | DN100 | 1200x850x1350 | 845 | 3.2 | Rp 1 ½" |
| LNLS-40 | 40 | 5.43 | DN100 | 1200x850x1350 | 955 | 4.1 | Rp 1 ½" |
| LNLS-50 | 50 | 6 | DN100 | 1200x850x1350 | 1020 | 4.3 | Rp 1 ½" |
| Note: LNLS is Water-Cooled type, others can be customized. Welcome to inquire for more details, WhatsApp No. +86 139 5809 5893 or E-mail: luther.liu@hzlinuo.com | |||||||
